PRODUCT
Military Steel Barrier
Heavy-Duty Steel Barriers for Military Perimeter Security & Vehicle Interdiction
Gallery
Steel Barrier Installation
Deployed at Facility Entrance
Crash-Rated Barrier Close-Up
Barrier Section Detail
OVERVIEW
Heavy-Duty Steel Barriers Engineered for Military-Grade Perimeter Security
Our military steel barriers are fabricated from high-strength ASTM A36 structural steel, designed to withstand vehicle-borne threats up to K12 rating (15,000 lb vehicle impacting at 50 mph). These barriers provide a permanent, maintenance-free perimeter defense solution for military bases, checkpoints, and critical infrastructure protection.
Unlike concrete barriers that crack and spall over time, welded steel barriers offer superior tensile strength, longer service life (20+ years with hot-dip galvanization), and the ability to be repaired or modified on-site. Our fabrication process ensures consistent quality with certified weldments and precision-fit connections.
Available in heights from 36 to 72 inches with multiple foundation options including direct embedment, base plate mounting, and portable skid-mounted configurations. Each barrier is engineered to meet or exceed NATO standards for force protection and anti-ram requirements.
Military-grade welded steel barrier installed for perimeter security
Specifications
Technical Specifications
Technical Specifications
Dimensions & Sizes
Custom sizes available upon request. All dimensions can be tailored to specific site requirements.
| Parameter | Value |
|---|---|
| Material | ASTM A36 / A572 Grade 50 Structural Steel |
| Impact Rating | K12 per ASTM F2656 (15,000 lb @ 50 mph) |
| Height Options | 36 in, 48 in, 60 in, 72 in |
| Steel Thickness | 3/8 in – 1 in (10ga – 25mm) |
| Weight per Linear Foot | 85 – 240 lbs depending on height & gauge |
| Finish | Hot-Dip Galvanized (ASTM A123) / Powder Coat |
| Foundation Type | Direct Embedment, Base Plate, Skid-Mounted |
| Certification | ASTM F2656 / IWA 14-1 / DoD UFC 4-020-01 |
FEATURES
Key Features
K12 Crash-Rated Construction
Engineered to ASTM F2656 standards, our barriers stop a 15,000 lb vehicle traveling at 50 mph with minimal penetration, providing certified anti-ram protection.
Hot-Dip Galvanized Finish
ASTM A123 compliant hot-dip galvanization provides 20+ years of corrosion resistance in outdoor environments, eliminating the need for ongoing maintenance.
Modular Welded Design
Factory-welded sections with precision bolt-together connections enable rapid installation while maintaining structural integrity equal to continuous welded construction.
Multiple Mounting Options
Choose from direct embedment in concrete, surface-mounted base plates, or portable skid-mounted units for flexibility across permanent and temporary installations.
Custom Height & Length
Available in 36, 48, 60, and 72-inch heights with custom lengths up to 12 feet per section to match specific site security requirements.
DoD UFC Compliant
Designed in accordance with Unified Facilities Criteria UFC 4-020-01 for DoD anti-ram barrier requirements and force protection standards.
Applications
Where It's Installed
Military Base Perimeter
Permanent anti-ram barriers protecting military installation perimeters from VBIED threats
Checkpoint Access Control
Vehicle entry control points with crash-rated barriers for secure facility access management
Border Fortification
National border security with continuous steel barrier lines for vehicle denial
Critical Infrastructure
Protection of government buildings, power stations, and vital national assets from vehicle attack
